Portable solar panels
Portable Solar Panel ECOFLOW 110W
110W solar panel, portable and foldable, with carrying case included. Powers ECOFLOW River & Delta stations or other equipment and stations that have similar performance, capacity and with MC4 solar connectors.
It cannot be plugged directly into a 12V battery (if it is not a battery or power station set up for it), you would need a solar regulator. Optionally, this solar regulator could be purchased to connect the panel to a 12V battery (the MC4 connectors that the panel comes with as standard would not work), although NO REGULATOR will be necessary if it is going to be connected only to an ECOFLOW power station or another brand with the same characteristics.
Panel weight: 4 kg.
Unfolded Dimensions: 51.4 x 158 x 2.4 cm.
Folded Dimensions: 51.4 x 42 x 2.4 cm.
Compatible with most portable power stations on the market (as long as they have the same technical characteristics), with MC4 connectors: 80 V (max.), 10 A (max.) for Delta portable generator and to USB-C: 25 V (max. .), 12 A (max.) for RIVER 600 series portable generator.
It is possible to connect several panels in series in parallel with suitable connectors. For ECOFLOW batteries, the connection will be made in parallel. It is possible to connect 2 X 110 W in the ECOFLOW River and 4 X 110 W in the Delta models. The chainable feature allows you to connect a maximum of four or more 110W ECOFLOW solar panels together with the MC4 cable.
Waterproof and Durable: The solar panel is waterproof to withstand all weather conditions. You can immerse the panel in water for up to 30 minutes without any detrimental effect on the product.
Rated power: 160w (+/- 5W)
Connector: MC4
Circuit Voltage: 21.7V (Vmp 18.5V).
Short circuit current: 6.3 (imp 6.0A).
Cell type: Monocrystalline silicon.
Operating temperature: -20°C to 80°C.
